Honda RS 250 GP 1997'

145906 visitors
2 visitors online
4563118 hits
Website online since 02/2006

Throttle Compilation 1
Piston: WISECO Kawasaki KX 500 86mm using both piston rings
Stroke: Stock (70mm)
Cylinder: Stock with iron cast sleeve, heavily tuned by LuFo, by changing the port timings and angles, passages reshaped for higher gas flow
Cylinder head: new head volume and squish angle for 12.8:1 CR using O'ring
Radiator: Stock + Honda CBR 600 radiator
Spark:NGK B9EG
Reeds: VFORCE Honda CR 250 carbon
Carburetor: Mikuni VM 44mm with new gigleur kit
Air Filters: LuFo's airbox with TwinAir filter
Electric part: Stock flywheel, with new variable ignition map LuFo CDI
Clutch: AAEN, with 3 gram weights
Silencer: Alloy PULSAR
Exhaust system: LUFO
Oil: Direct mixture in the deposit, 2%
Transmission: Kevlar AAEN drag belt with stronger spring
Engine maximum rotation in charge: 8 600rpm
HorsePower (crankshaft): Over 65hp
HorsePower (rear wheel): Over 40 hp
Maximum Real Velocity: 120 km/h
Wheels: ITP polished wheels for Yamaha Raptor 660
Tires: DURO rear tires 20/11/10' and TITAN front tires 21/7/10'
Brakes: stock, with Carbon Lorraine brake pads
Braking system: stainless steal.
Suspension: Stock suspensions modified by MXT
Steering Damper: 3 possible regulations.
Frame: stock modified and powdercoated in grey
Swingarm: Stock painted in gold with DG alloy protections
Chain: IRIS 520 gold
Fenders: Polaris Scrambler 500
Handlebar: HEBO
Bumper: DG Alloy Series
Decals: Factory FX
Nerf-Bars: DG
